Hot Plate, HPT Series
Category:Ovens, Furnaces & Baths

Hot Plate, HPT Series

Infitek

  • Max Temp.（℃）: HPT-320-5B/8B /9B: 320℃ MGS-5,HPT-320-8B,HPT-350-9B: 350℃ HPT-400-5B,HPT-400-8B,HPT-400-9B: 400℃
  • Temp. accuracy: HPT-320-5B,HPT-320-8B,HPT-320-9B: ±10% MGS-5,HPT-350-8B,HPT-350-9B,HPT-400-5B,HPT-400-8B,HPT-400-9B: ±1%

Pricing and availability are quoted per request. Ask about specifications, lead times, or tender documents.

Request a quote
WhatsAppViberCall
Technical parameters
BrandInfitek
CategoryOvens, Furnaces & Baths
ModelHPT-320-5B / HPT-320- 8 B / HPT-320- 9 B / HPT-350- 5 B / HPT-350- 8 B / HPT-350- 9 B / HPT-4 0 0-5B / HPT-4 0 0- 8 B / HPT-4 0 0- 9 B
Work plate dimension(mm)300×300 / 350×450 / 400×600
Work plate load(kg)20 / 30 / 40
Work plate materialAluminum-tensile / Graphite Plate
Time settingNo / 0~9999min/h
Temperature settingScale / Digital display
Max Temp.(℃)320 / 350 / 400
Temp. accuracy±10% / ±1%
Plate Temp. uniformity±15% / ±10%
Temperature sensorK model
Heating power(W)800 / 1500 / 2200 / 1200 / 2400 / 3500 / 1800 / 3000 / 4500
Power supply(50/60Hz)220V
PlugYes / No
Exterior size(W×D×H) (mm)340×370×220 / 420×500×220 / 470×650×220
Packing size(W×D×H) (mm)520×380×250 / 570*530*260 / 660×620×250 / 560×520×250 / 700*660*260 / 550×410×270 / 600×560×270 / 700×660×270
NW/GW (kg)9/10 / 11/16 / 15/17 / 11/12 / 15/25 / 12/13.5 / 19/20 / 28/30
DatasheetAvailable on request

Values separated by “/” refer to different models in the series. Confirm the exact configuration when requesting a quote.
