Constant Temp. & Humidity Chamber, ICB-H-YH Series
Category:Incubators

Constant Temp. & Humidity Chamber, ICB-H-YH Series

Infitek

  • Capacity: 103L, 152L, 253L, 412L, 722L, 1022L
  • Temperature Range: -5~70℃
  • Humidity Range: 15%~95%RH
  • New diffusion-type air duct circulation system improves the uniformity of temperature and humidity

Pricing and availability are quoted per request. Ask about specifications, lead times, or tender documents.

Request a quote
WhatsAppViberCall
Technical parameters
BrandInfitek
CategoryIncubators
ModelICB-H103YH / ICB-H152YH / ICB-H253YH / ICB-H412YH / ICB-H722YH / ICB-H1022YH
Capacity (L)103 / 152 / 253 / 412 / 722 / 1022
Circulation ModeForced Convection (Balanced Type)
Dimension (W*D*H)Internal (mm) / 480*390*550 / 500*460*660 / 640*460*860 / 560*530*1390 / 980*530*1390 / 980*750*1390
External (mm)645*700*1255 / 665*780*1360 / 800*780*1570 / 1025*810*1735 / 1445*810*1735 / 1445*1030*1735
TemperatureRange (℃) / -5~70
Resolution (℃)0.1
Fluctuation (℃)±0.2 / ±0.5
Uniformity (℃)±0.5 / ±1
HumidityRange / 15%~95%RH
Fluctuation±1%RH / ±1.5%RH
Operating Ambient Temperature (℃)5-30
Shelves (Standard)2 / 3 / 4
Test Hole (mm)φ40
ElectricityVoltage/Frequency / AC 220V, 50Hz
Consumption (W)1300 / 1400 / 2000 / 2500 / 3500 / 3800
Safety ProtectionRefrigeration System / Compressor overheating, over-current and over-pressure protection; condenser fan overheating protection.
OthersMain power phase sequence and phase loss protection; Leakage and short-circuit protection; Overload protection; Water shortage protection.
DatasheetAvailable on request

Values separated by “/” refer to different models in the series. Confirm the exact configuration when requesting a quote.
